• Transparente vertikale Gläser mit Prismenschliff: Für verbesserte Ausleuchtung in einem breiten Winkel.
• Typ FB: Eingebauter akustischer Alarm mit einer Lautstärke von 90 dB bei 1 m.
• Installation: Vertikal und horizontal.
• Gehäusefarbe: Hellgrau
• Lampenglas: Gefertigt aus temperaturbeständigem und besonders schlagfestem Polycarbonat-Harz für erhöhte Lebensdauer und gute Lichtdurchlässigkeit.
• NPN/PNP-kompatibel: Direktanschluss an PLC (NUR 24 V DC)
• Lichtmuster: Blinkend und kontinuierlich.
• Staubdicht und wasserresistent gemäß Schutzklasse IP65 (außer Typ FB: IP54).
• Verfügbare Farben: rot, gelb, grün, blau, transparent/weiß.
DIMENSIONS | - 37.5mm profile |
---|---|
RATED VOLTAGE | - 24V AC/DC |
FUNCTIONS | - Continuous Only - Continuous, Alarms |
MOUNTING | - Wall Mount |
BODY STYLE | - Pre-assembled, pre-wired |
BODY COLOR | - Body: light gray |
STACKABLE TIERS | - Available from 3 to 5 tier versions |
MODULE COLORS | - Red - Amber - Green - Blue - Clear |
AUDIBLE STYLE | - Alarm 1: selectable, single-tone, intermittent (fast beep) alarm, 90dB (at 1m) - Alarm 2: selectable, single-tone, intermittent (slow beep) alarm, 90dB (at 1m) |
CONFORMITY STANDARDS | - UL Listed (E215660) |
PROTECTION RATING | - IP65 (außer Typ FB: IP54) |
