• Includes an M-12 Quick Connector.
• PATLITE's exclusive hybrid prism-cut lens to enhance visibility from any direction and distance.
• Double Insulation for enhanced durability and safety in the work environment.
•Direct mount installation with just a single hole.
• Interchangeable LED modules needing no re-wiring, even after installation.
• Main Body made of heat resistant ABS resin for superior impact resistance.
• Lens made with light translucent AS resin for superior weather resistance.
• Available colors are in Red, Amber and Green.
DIMENSIONS | - 30mm diameter |
---|---|
RATED VOLTAGE | - DC 24V (Non-polar) |
FUNCTIONS | - Continuous Lighting Only - Dry contact closure such as switches or relay contacts - Open-collector transistor (NPN or PNP) for DC24V - Direct voltage control |
MOUNTING | - Direct mount only: includes M22 mounting nut and sealing gasket |
BODY STYLE | - M-12 Quick Connector (Cable sold separate) - Pre-assembled, pre-wired - Modules interchangeable and stackable after purchase |
BODY COLOR | - Body: Silver |
STACKABLE TIERS | - From 1 to 3 modules can be stacked |
MODULE COLORS | - Red - Amber - Green |
CONFORMITY STANDARDS | - CE Marking - UL Component Recognition (US) - c-UL Component Recognition (Canada) - RoHS Compliant |
PROTECTION RATING | - IP 65 |
